Zebra ZD621R Desktop Thermal Transfer Printer – The Ultimate RFID Printing Solution

Looking for a high-performance, reliable RFID thermal transfer printer? The Zebra ZD621R delivers premium printing and encoding in a compact, user-friendly design. Ideal for businesses needing to print labels, receipts, and RFID tags, this printer offers best-in-class features and unmatched security. Whether you’re in retail, healthcare, manufacturing, or logistics, the ZD621R is engineered to meet your evolving needs.

Best Features:

• High-Quality Printing: Prints at 300 dpi for crisp, clear labels and receipts.
• RFID Encoding: Integrated Zebra RE40 RFID reader/encoder for versatile RFID applications.
• User-Friendly Design: 4.3-inch color touch LCD for intuitive operation and easy setup.
• Advanced Connectivity: Includes Ethernet, USB, USB Host, Serial, and Bluetooth Low Energy (BLE) for seamless integration.
• Print DNA Software Suite: Easy to set up, use, manage, and secure your printer.
• Compact Footprint: Saves valuable desk space without compromising performance.

Technical Specifications:

• Print Method: Thermal Transfer
• Resolution: 300 dpi
• Print Speed: Up to 6 inches per second (ips)
• Maximum Print Width: 4.09 inches (104 mm)
• Memory: 512 MB Flash, 256 MB SDRAM
• Connectivity: USB 2.0, USB Host, Serial, Ethernet, BTLE 5
• RFID: UHF EPC Gen 2 V2, ISO/IEC 18000-63, RAIN RFID protocols
• Display: 4.3-inch color touch LCD (480 x 272 resolution)
• Dimensions: 8.7 in. x 6.9 in. x 5.9 in
• Weight: 2.49 kg

Compatible Consumables:

• Ribbons: Supports both 74-meter and 300-meter ribbon lengths. Use wax, wax/resin, or resin ribbons depending on your application.
• Labels: Compatible with a wide range of direct thermal and thermal transfer labels.
• Specialty Media: Supports tags compatible with UHF EPC Gen 2 V2, ISO/IEC 18000-63, and RAIN RFID protocols.
• Accessories: Optional cutter, peeler, and other media handling options are available.

How to Use:

1. Load the ribbon and labels.
2. Connect the printer to your computer via USB, Ethernet, or Serial.
3. Install the Zebra printer drivers.
4. Configure printer settings via the LCD touch screen or Zebra Print DNA software.
5. Start printing your labels and RFID tags.

Manufacturer Recycling/Return Programs:

Zebra is committed to environmental responsibility. While a formal recycling program for used ribbons may not be widely available, some initiatives are in place. SATO has launched a recycling program in Japan for used ink ribbons. Contact Zebra or your local waste management services to inquire about recycling options for electronic components and plastics. Some manufacturers offer take-back programs for spent cartridges. Consider returning used ribbons to manufacturers if such programs exist.

Maintenance and Care:

To ensure optimal performance and longevity of your Zebra ZD621R printer, follow these maintenance tips:

• Regular Cleaning: Clean the print head each time you change the ribbon or label roll. Use a lint-free cloth and isopropyl alcohol to gently wipe the print head.
• Platen Roller Cleaning: Clean the platen roller with a lint-free cloth and isopropyl alcohol to prevent feeding issues.
• Sensor Cleaning: Clean the sensors near the print head to ensure accurate label detection.
• Dust Removal: Regularly remove dust and debris from the printer interior using compressed air or an anti-static vacuum cleaner.
• Proper Storage: Store label stock in a cool, dry environment to prevent degradation.

Conclusion:

The Zebra ZD621R is the perfect choice for businesses seeking a reliable, high-performance RFID thermal transfer printer. With its advanced features, user-friendly design, and robust security, the ZD621R delivers exceptional value and performance. Upgrade your printing capabilities today!
