StarTech.com Cisco Meraki MA-SFP-10GB-SR Compatible SFP+

Upgrade your network with the StarTech.com Cisco Meraki MA-SFP-10GB-SR compatible SFP+ transceiver. This module provides a reliable and cost-effective solution for adding 10 Gigabit Ethernet connections over multi-mode fiber to your Cisco Meraki switches and routers. Ideal for data centers and enterprise networks, this SFP+ transceiver delivers the performance and compatibility you need to keep your business running smoothly.

Best Features:

• 100% Cisco Meraki Compatible: Designed, programmed, and tested to work seamlessly with Cisco Meraki equipment, such as MS225, MX400, MS250, MS350 and MS425 series switches.
• High-Speed 10GbE Connectivity: Provides dependable 10 Gigabit Ethernet connections for 10GBASE-SR compliant networks.
• Multi-Mode Fiber Support: Optimized for use with multi-mode fiber (MMF) cables, ensuring efficient data transmission over shorter distances.
• LC Duplex Connector: Features an LC duplex connector for easy and secure connection to fiber optic cables.
• 300m Reach: Supports distances up to 300 meters (984 feet).
• Hot-Swappable: Allows for easy installation and replacement without interrupting network traffic.
• Digital Diagnostics Monitoring (DDM): Supports DDM, providing real-time monitoring of operating parameters.

Technical Specifications:

• Product Type: SFP+ Transceiver Module
• Data Transfer Rate: 10 Gbps
• Wavelength: 850nm
• Fiber Type: Multi-Mode Fiber (MMF)
• Connector Type: LC Duplex
• Max Distance: 300m (984 ft)
• DDM Support: Yes
• MTBF: 1,967,709 hours
• Power Consumption: < 1.2W
• Standards: IEEE 802.3ae 10GBASE-SR
• Compliancy: MSA Compliant
• Hot Pluggable: Yes

Networking Equipment Features:

• Network Standards: 10 Gigabit Ethernet (10GBase-SR)
• Data Transfer Rate: 10 Gbps
• Number of Ports: 1
• Management Features: N/A (This is a transceiver, not a managed device)
• Security Protocols: N/A (Security depends on the connected networking equipment)

How to Use:

1. Ensure your Cisco Meraki switch or router is powered off or the port is administratively down.
2. Remove the dust cover from the SFP+ transceiver and the corresponding port on your device.
3. Align the transceiver with the SFP+ port and gently slide it in until it clicks into place.
4. Connect the LC duplex fiber optic cable to the transceiver.
5. Power on your device or enable the port.
6. Verify the connection using the appropriate commands in your device’s management interface.

Warranty & Support:

This StarTech.com SFP+ transceiver module is backed by a lifetime warranty and free lifetime multilingual technical support.

Conclusion:

Boost your network performance with the StarTech.com Cisco Meraki MA-SFP-10GB-SR compatible SFP+ transceiver. Offering reliable 10GbE connectivity, seamless compatibility, and a lifetime warranty, this is the perfect upgrade for your Cisco Meraki network. Add to cart now!
